How To Measure Brakes
To measure a Brake Shoe You simply take a tape measure and place it across the face of the shoe. This gives you the measurement for the width of the shoe and is extremely helpful to know when purchasing your Brake Shoes

To measure a Brake Drum You need to place a tape measure along the inside of the brake drum. This gives you your internal diameter and helps determine which brake it is you need.

Common KNOTT & AL-KO Sizes

KNOTT
160mm x 35mm
200mm x 50mm
203mm x 40mm
250mm x 40mm


AL-KO

160mm x 37mm

200mm x 35mm

200mm x 51mm

230mm x 61mm
