Additional information
Manufacturer | Variant |
---|---|
Product Code | 2015 M2 |
Series | Auto-Transporters, Commercial Box Trailers, Machine Series, Tipper Trailers |
Internal Dimensions (LxWxH) | 260x150x30 cm |
Total Dimensions (LxWxH) | 439x204x173 cm |
Tare Weight | 560 kg |
Total Weight (ATM) | 2,000 kg |
Payload Capacity | 1,440 kg |
Loading Height | 40 cm |
Wheels | 13", 5 Studs, 5 Wheels (4+spare) |
Axles | 2 Axles, With Brakes |
Side Material | Galvanized Steel |
Floor Material | Phenolic Plywood 18mm |
Interior Tie Down Anchor Points | 2 Hooks |
Exterior Lashing Hooks | 6 Hooks |
Ramp Angle | 17 degrees |
Other Included Features | 13 or 7 Pin Plug, Anti-Slip Tred Plates, Gas Struts On Back Ramp, Jockey Wheel, Parabolic Leaf Springs, Platform For Shovel, Spare Wheel, Strong Tailgate Ramp 130cm |
Optional Extras | Aluminium Floor Material, LED Lights Kit with Control Box, Tie-Down Rings Base Mounted, Wheel Change to 13" Terrain, Wheel Change to 14" High Profile |
Rough Size In Feet | 8.5×5 |
