2in1 Toilet Trailer 240

Portable toilet trailer

Provides two toilet and hand basin cubicles in one simple solution.

The 2in1 Toilet Trailer 240 is often used by:

  • People whose homes are undergoing renovation
  • Construction and building sites where staff need access to an on-site toilet.
  • Outdoor events such as parties, weddings, markets, parades and performances.

All Scanvogn cabins are customisable so if the standard solution isn’t quite what you need,  you can make your portable toilet exactly the way you want it. There is a range of additional options that can be included.

Toilet Type

Standard 240 Model A – Tank Toilet

The tank toilet is our simplest toilet solution. It has a tank capacity of 200 visits and comes with a 65 L water stand, which functions as both a hand basin and flushing mechanism. The toilet does not require any power and can therefore work as an independent solution. Thanks to the toilet’s construction, it cannot get blocked and therefore rarely needs servicing. The tank has a ventilation pipe to remove any odours.

Standard 240 Model B – Water Flushing Toilet With Waste Disposal

This model comes equipped with our standard flushing toilet waste disposal. For people who have a connection to external water and drainage on site, then this is the toilet solution for you. The toilet works like a normal toilet in the home (but with disposal for extra reliability) and therefore feels natural and comfortable. We supply the toilet in an upright or wall-mounted version, and with or without visible pipes. If the pipes are hidden, the cabin is built with a technical compartment, for easy servicing of the toilet.

Standard 240 Model C – Water Flushing Toilet With Waste Disposal + External Urinal

Adding an external urinal and external hand basin means you can increase the capacity of visits at any one time. See the video here to view how the external urinal is set up.

Easy To Use & Clean

The trailer is connected to a standard towbar and can be set up and ready in a few minutes. This makes it possible to move the trailer from place to place quickly and efficiently without any hassle. The trailer is made of clean and durable materials, and sleek minimalistic designs, saving time for cleaning and maintenance.

Scanvogn portable shower & toilet block trailers are ideal for a range of industries and applications such as:

  • Music Festivals
  • Catering & Hospitality Events
  • Field Day Events
  • Glamping Grounds
  • Horse & Country Events
  • Motor Racing
  • Construction & Demolition Sites
  • Exhibitions & Shows
  • Outdoor Events
  • Private Functions
  • Sporting Events

The trailers provide easily accessible, clean and hygienic ablution facilities for customers, guests and staff.

Also available in a larger sized unit called the 420 4+2 with 4 toilets, 2 urinals & 2 hand basis, 570 model -5+2 urinals & 3 hand basins. (with a partition wall if you want to separate men & women).
Categories: , Tags: , , , , , ,

Additional information

Weight 5 kg
Manufacturer

Scanvogn
Model Name

Model A – 240 2in 1 toilet unit with tank toilet Model B – 240 2in 1 toilet unit with flushing toilet Model C – 240 2in 1 toilet unit with flushing toilet & external urinals
Model Number

Model A (Tank) – 1800108/1850004 Model B – (Flush) – 1800106/1850002 Model C – (External Urinal) – 1003328/1852870
Internal Dimensions

1906 x 1746 x 2100 mm
External Dimensions

2400 x 1850 x 2700 mm
Own Weight

700 kg
Total Weight

750 kg
Capacity

1 person
Facilities

*NOTE. Varies between models. 2 toilets 2 hand basins 2 external hand basins (Model C only) 4 tempo taps External urinal (Model C only) 4 towel holders, 4 coat hooks 2 windows 510 x 410 mm Technical compartment, fan heater 2 tilting steps 230 V – 16 A CEE inlet, 230 V – 16 A CEE outlet 15 L water heater LED light strip Electrical circuit panel

Description

The 2in1 Toilet trailer with 2 cubicle toilets and water basins. Toilets are water flushable with an external waste connection and water or tank. Elegant design, galvanised, easy to use and clean, completely portable.
• AL-KO CHASSIS – Using German AL-KO parts on all standardized chassis to ensure you one of the best trailer systems on the market. Rubber torsion-independent suspensions make a smoother ride with maximum protection of goods being carried.
• VISABILITY – All external vehicle lights are high and low, high-quality LED sealed for high visibility whilst travelling.
• BEST PROTECTION – Galvanizing is carried out after the chassis has been mechanically machined so that all edges and bolt holes are also protected.
• FULLY MOLDED CURVED ROOF – Molded roof with a smooth curvature to optimize strength and direct water/snow and dirt away from the centre of the roof to the gutter -front and rear.
• GUTTER SYSTEM – Directional gutters along the sides to gutter at each gable to direct water and dirt away from users, doors and windows.
• DURABLE PANELS – Using UV-stabilised bright white fibreglass which contains a high number of fibres for best strength and durability. Totally weatherproofed and the perfect base for vinyl wrapping.
• EU – CERTIFIED – All our standard windows are gas-filled double glazing for extreme thermal efficiency, and screen boxes and lights are EC certified. Our wagons can therefore be driven legally throughout the EU and Au, in extreme heat and cold.
• STRONG WALLS – All external walls are seam cut and placed so that the angles close tightly around the floor for maximum strength and tightness.
• ENERGY-FRIENDLY LIGHT – Using daylight white LED light strips in all rooms, which gives you a comfortable white and energy-friendly light with a modern look.
• SPECIAL COMPONENTS – We produce several of our own sub-components ourselves, so we can offer you higher quality at a reasonable price.
• GUARANTEED SPARE PARTS – We have a large spare parts warehouse, where most parts can be shipped from day to day.
• COMPACT LAMINATE – All our table tops are high-density compact laminate which will not rot or create mould. This makes them resistant to water and humidity & bacteria. Excellent for testing or catering rooms.
• TOUCH-FREE FITTINGS – Option to choose touch-free fittings or toilet flush. (Specific to Covid-19 compliance) With durable/fully washable materials, so you spend as little time on cleaning and maintenance as possible.
• SPACIOUS – With ceiling heights of 2100mm and bigger and widths from up to 2380mm, we pride ourselves on having the most spacious models.
• TOWABILITY – Our trailer systems use lightweight low-tare strong chassis, combined with very lightweight panels, we know we have the lightest, most efficient mobile room system available. Overrun mechanical all-wheel drum braked, with breakaway safety cables and independent handbrake – there is no adjustment needed by the user.
• ROI – All in all, with great resale values, this gives you the best business investment, easiest to manage, most sustainable fuel-saving mobile trailer system, on the market.
